Fanless Intel Mini PC Core i7 1255U i5 1235U Gaming Office Micro Desktop Computer 8*USB HD DP 4K

Experience powerful, fanless computing with the Intel Core i7 & i5 Mini PC. This tiny desktop packs a tremendous gaming, office, and home-entertainment punch, with 8*USB, HD, and DP ports for unparalleled versatility. Product Highlight- Intel processor, assure powerful performance for gaming, office, drawing;- Onboard  Intel Iris Xe Graphics on...
Memory Capacity
Color
Core i5-1235U Black
Core i7-1255U Black
Core i7-1165G7 Black
Hard Drive Capacity
-
+
₱34,649.99

Mini Computer

Experience powerful, fanless computing with the Intel Core i7 & i5 Mini PC. This tiny desktop packs a tremendous gaming, office, and home-entertainment punch, with 8*USB, HD, and DP ports for unparalleled versatility.


Product Highlight
- Intel processor, assure powerful performance for gaming, office, drawing;
- Onboard  Intel Iris Xe Graphics on i7-1255u that is comparable to NVIDIA GeForce MX450 discrete graphics card;
- 2*DDR4 SODIMM RAM slots 2xfaster than 1 ram slot, DDR4 2xfaster than DDR3;
- Triple-Storage: support 1*MSata SSD+1*M.2 NVME(22x80) SSD+1*2.5'' SATA SSD/HDD;
- Noiseless: Fanless system, all aluminum passive heatsink, low consumption, 0.00dB noise;
- Slim volume: Can stand on desk by free bracket, mount back of monitor by VESA bracket(optional).


What In The Package:
1*Mini PC
1*AC adapter
1*Power cord
1*WiFi module and antennas ("Barebone Mini PC" bundle package without WiFi module and antennas )
1*Stand Bracket
1*Screws bag
1*SATA Power cable & data cable



Basic information







CPU
1. 8th Gen 14nm CPU Intel Core i7 8550U 4 cores 8 threads 1.8GHz up to 4.0GHz 8MB cache TDP 15W Intel UHD Graphics 620. (probably send i7 8559U,i7 8565U,i7 8569U by random)
2. 8th Gen 14nm CPU Intel Core i5 8250U 4 cores 8 threads 1.6GHz up to 3.4GHz 6MB cache TDP 15W Intel UHD Graphics 620. (Probably send i5 8265u / i5 8350U by random)
3. 10th Gen Onboard Intel Comet Lake Intel Core i7 10510U 1.8GHz up to 4.90GHz Quad Cores 8 Threads TDP 15W.8MB Cache.Intel UHD Graphics(300Mhz-1.15GHz)
4.10th Gen Onboard Intel Comet Lake Intel Core i7 10710U 1.1GHz up to 4.7GHz 6 Cores 12 Threads TDP 15W.12MB Cache.Intel UHD Graphics(300Mhz-1.15GHz)
RAM
Support 2*DDR4-2666/2400/2133 laptop ram Maximum 32GB RAM
Storage
Support 1*mSATA SSD+1*M.2(NVMe) SSD+1*2.5'' SATA HDD/SSD installation together
Graphics
Intel graphics UHD 620, support ultra HD 4K resolution
I/O
Mic; Speaker; 4* USB 3.0 port; 4* USB 2.0 port; 1* RJ45 Gigabit LAN Port; 1* VGA(DP); 1* HD; 1* DC In;
Operating System
Win10, Linux Compatible, OpenELEC
Language
Multi Language
Feature
Fanless system design, without noise
USB port
4*USB 3.0+4*USB 2.0
Wireless
802.11.b/g/n, 300M 2.4G/5G dual band WiFi with 2 Antennas( exclude "No Ram No Storage" bundle)
HD Output
1* HDMI port, 1* VGA(DP) port, support HD+VGA(DP) dual display
LAN port
1* Gigabit Realtek RJ45 Lan speed up to 1Gbps
Weight
2.5 KG
Other Important Information
Material
Brushed Aluminum Alloy
Weight
NW:2.0Kg GW:2.5Kg
Package Content
1* Mini PC; 1* power adapter; 2* Antennas etc
Warranty
1yr
Certification
FCC, Ce, ROHS, BIS(ISI)
Plugs Type
US, JP, CN, AU, UK, EU
Mouse & Keyboard
NO
After-sales Service
Return and Replacement
Switch
1 * Power On/Off Switch
Power
1 * DC In
LED
1*LED
